Spalling refers to the breaking, cracking, or flaking of refractory materials due to thermal, mechanical, or chemical stress. It is one of the most common causes of refractory failure, especially in high-temperature industrial environments such as furnaces, kilns, and incinerators. Understanding the types of spalling, its root causes, and the best practices to mitigate it is critical to improving refractory performance and longevity.
What is Spalling?
Spalling is a form of material degradation where layers or chunks of refractory lining detach due to internal stresses. These stresses can be caused by rapid temperature changes, chemical reactions, mechanical load, or structural fatigue.
This damage leads to a reduced thermal barrier, increased energy consumption, and eventual refractory failure—potentially causing shutdowns or expensive repairs.
Common Causes of Spalling
Spalling is rarely caused by a single factor. It usually results from a combination of conditions:
- Thermal Shock: Rapid heating or cooling leads to uneven expansion or contraction, causing cracks.
- Hydration: Moisture in the refractory reacts at high temperatures, creating steam pressure that leads to cracking.
- Chemical Attack: Corrosive slags or gases (e.g., alkalis, acids) degrade the refractory microstructure.
- Mechanical Stress: Abrasion or impact from load, tools, or materials can weaken surfaces.
- Structural Weakness: Poor installation, low-quality bricks, or improper curing can lead to internal tension.
Types of Spalling
Different types of spalling can occur depending on the nature and source of stress:
- Thermal Spalling: Occurs due to rapid temperature fluctuations. Common in furnaces with frequent cycles.
- Mechanical Spalling: Caused by wear, impact, or vibration during operation.
- Explosive Spalling: Sudden release of trapped moisture or gases, often violent and dangerous.
- Chemical Spalling: Results from aggressive reactions between the refractory and process materials.
Industrial Sectors Affected by Spalling
Spalling affects nearly every industry that operates with high temperatures:
- Glass Industry: Float glass furnaces are prone to thermal cycling, making spalling a frequent issue.
- Steel Plants: Ladles and converters face extreme mechanical and chemical stress.
- Cement Kilns: Rotary kilns and preheaters experience both thermal and chemical spalling.
- Petrochemical: Reactors and reformers handle harsh chemicals at high heat.
How to Detect Early Signs of Spalling
Early identification is essential to limit damage:
- Visible cracks or delamination on the lining surface
- Reduced thermal performance or hot spots
- Unusual sound during operation (drumming effect)
- Changes in temperature profiles or heat loss
Tip: Regular thermal imaging and inspection are effective tools for spalling detection.
How to Prevent Spalling in Refractories
To improve refractory service life and prevent spalling, apply these best practices:
- Controlled Heating & Cooling: Use ramp-up and ramp-down protocols to manage thermal shock.
- Dry-Out Procedures: Remove all residual moisture during initial curing or shutdowns.
- Correct Material Selection: Choose spalling-resistant refractories with high thermal shock resistance.
- Proper Installation: Ensure professional supervision and adherence to installation guidelines.
- Preventive Maintenance: Schedule regular inspections and small repairs to avoid escalation.
Case Example: Spalling in Glass Furnace Regenerator
In a recent audit conducted by MXS Refractories in a Middle Eastern glass plant, extensive spalling was detected in the regenerator checkerwork due to improper cooling during shutdown. After diagnosing the root cause, MXS supervised the installation of new shock-resistant checker bricks, along with modified cooling procedures. The plant reduced refractory wear by 40% over the next 12 months.
Expert Tip from MXS Refractories
Spalling isn’t just a material issue—it’s often a systems problem. Working with independent experts like MXS allows you to identify systemic weaknesses in design, installation, and operation—not just the visible damage.
